Product Summary

Absolute Maximum Ratings (Ta = 25°C)
Characteristic Symbol Rating Unit
Forward current IF 50 mA
Forward current derating (Ta > = 25°C) ΔIF/°C ?0.5 mA/°C
Peak forward current
(100 μs pulse, 100 pps) IFP 1 A
Reverse voltage VR 5 V
Led
Junction temperature Tj 125 °C
Off-state output terminal voltage VOFF 400 V
TLP227GA
One
channel On-state
current TLP227GA-2
Both
channel
ION 120 Ma
TLP227GA
One
channel
On-state
current
rating
(Ta > = 25°C) TLP227GA-2
Both
channel
ΔION/°C ?1.2 mA/°C
Detector
Junction temperature Tj 125 °C
Storage temperature range Tstg ?55~125 °C
Operating temperature range Topr ?40~85 °C
Lead soldering temperature (10 s) Tsol 260 °C
Isolation voltage (AC, 1 min., R.H. < = 60%)
(Note 1) BVS 2500 Vrms
